Straight

Air nozzle

•

  Air Jet AJ-B

  Features	For large flow rate blowers
  Pressure Range [MPa]	5 - 50
  Maximum Air Flow Rate [m³/min (nor)] at 10 kPa	2
  Spray Width [mm] at 10 kPa	200 (at 500 mm)

•

  Air Jet KSVR

  Features	Quiet, with highly-straight flow
  Pressure Range [MPa]	0.1 - 0.7
  Air Flow Rate [L/min (nor)] at 0.3 MPa	180 - 470
  Spray Width [mm] at 0.3 MPa	21 - 23 (at 100 mm)

•

  Air Jet KSV

  Features	Supersonic design
  Pressure Range [MPa]	0.1 - 0.7
  Air Flow Rate [L/min (nor)] at 0.3 MPa	64 - 4466
  Spray Width [mm] at 0.3 MPa	16 - 25 (at 100 mm)

Hydraulic nozzle

•

  Mini/Straight Jet Mini KSJ

  Features	Compact
  Pressure Range [MPa]	0.1 - 0.7
  Orifice Diameter [mm]	0.5 - 2.0
  Tip Materials	Stainless steel (JIS SUS303)

•

  Straight Jet KSS - T

  Features	Moderate to high pressure washing
  Pressure Range [MPa]	1 - 10
  Orifice Diameter [mm]	1.0 - 5.0
  Tip Materials	Stainless steel (SUS420J2, SUS440C)

•

  Straight Jet Separate TSJ

  Features	Moderate to high pressure washing
  Pressure Range [MPa]	1 - 10
  Orifice Diameter [mm]	1.0 - 5.0
  Tip Materials	Stainless steel (SUS420J2, SUS440C)

•

  Straight Jet HCJP

  Features	High pressure cleaning nozzles
  Pressure Range [MPa]	1 - 10
  Orifice Diameter [mm]	1.0 - 5.0
  Tip Materials	Cemented carbide

•

  Straight Jet Separate TCJP

  Features	High pressure cleaning nozzles
  Pressure Range [MPa]	1 - 10
  Orifice Diameter [mm]	1.0 - 3.0
  Tip Materials	Cemented carbide

•

  Straight Jet Separate TCJS

  Features	High pressure cleaning nozzles
  Pressure Range [MPa]	1 - 10
  Orifice Diameter [mm]	1.0 - 5.0
  Tip Materials	Cemented carbide

•

  Self-Cleaning SCJ

  Features	Clog-resistant, and self-washing
  Pressure Range [MPa]	0.1 - 5
  Orifice Diameter [mm]	0.5 - 1.5
  Tip Materials	Stainless steel (JIS SUS303)

•

  Straight Jet KSJ - C

  Features	Laminar flow without scattering
  Pressure Range [MPa]	0.3 - 5
  Orifice Diameter [mm]	0.3 - 1.5
  Tip Materials	Stainless steel (JIS SUS303), Cemented carbide, Ruby, Ceramics

•

  Straight Jet KSJ - S

  Features	Laminar flow without scattering
  Pressure Range [MPa]	0.3 - 5
  Orifice Diameter [mm]	0.3 - 2.0
  Tip Materials	Stainless steel (JIS SUS303) , Cemented carbide , Ruby , Ceramics
