Specifications
| Pressure Range [MPa] | 1 - 10 |
| Orifice Diameter [mm] | 1.0 - 5.0 |
Materials
| Standard Materials | Tip: Cemented carbide (solid) Cap: Stainless steel (SUS303) Adapter: Stainless steel (SUS303) |
Dimensions
| TCJS |
|---|
|
|
| Model | Dimensions L[mm] | Connecting thread |
|---|---|---|
| 1/2 TCJS | 81.5 (91.5) | R 1/2 |
| 3/4 TCJS | 81.5 (91.5) | R 3/4 |
There are 2 nozzle tip lengths: 30 mm and 40 mm. Dimensions for 40 mm tip are in parenthesis.
