EVERLOY has supported uses as leading company of customized spray nozzle. This section shows basic knowledge and types of spray nozzle.

Spray nozzle

Spray nozzle is mechanical parts which control flow, width, fineness and impact by required pressure. Image hose connected tap water at your home. Impact and water volume are low if you just turned tap water open little bit. It is not good if you would supply water to flower at your garden.
If you push front edge of hose, water is spread and force become bigger which water can reach more far. You can control water flow like this. Spray nozzles work like pushing front edge of hose.

Typically, you don't have chance to see spray nozzles often because it is typically used for industry. Our products are typically used at various kinds of factories too though, spray nozzles which creates fine mist are also used at public space such as park or restaurant.
There are various size of spray nozzles which is not only handy size, but a few meters also. They are properly selected for many kinds of industries such as steel or incineration plant.

Types of spray nozzle

There are various kinds of spray nozzles then used for many application. Types of spray nozzle are categorized due to spray pattern.

1. Flat fan pattern
2. Full cone pattern
3. Hollow cone pattern
4. Straight pattern
5. Curtain pattern

You can get great solution by selecting spray pattern properly for your application, because each spray pattern has each character.

Flat fan pattern nozzle

Hydraulic nozzle, two- fluid nozzle and air nozzle can create flat fan pattern. It is typically used for washing or descaling because it can create high impact due to thin spray thickness.
It is possible to improve impact or reduce water consumption by optimizing spray angle.

Relevant information
Learn more

Full cone pattern nozzle

Hydraulic nozzle, two-fluid nozzle and air nozzle can create full cone pattern which is filled cone. It can cover wide area, and it can reduce nozzle Q'ty or uniform spray by optimizing spray angle.

Relevant information
Learn more

Hollow cone pattern nozzle

Hollow cone pattern spray nozzle is typically used as hydraulic nozzle. It can cover wide area, but more fine particle compared to full cone pattern nozzle. It is used for various kinds of industries because it can spray tiny flow rate.

Relevant information
Learn more

Straight pattern nozzle

Hydraulic nozzle, two-fluid nozzle and air nozzle can spray straight pattern, It can create high impact instead of no spray width. Major applications are cutting, washing or eliminating foreign materials by high pressure. They use anti-wearing material such as cemented carbide for nozzle orifice.

Relevant information
Learn more

Curtain pattern nozzle

Hydraulic nozzle, two-fluid nozzle and air nozzle can create curtain pattern nozzle. It can spray with wide range with uniform distribution. We can manufacture spray nozzle which is more than 3 meters long nozzle with uniform distribution.

Relevant information
Learn more

Contact us

We can supply 2,200 kinds of hydraulic nozzle, two-fluid nozzle and air nozzle as standard models. Customized nozzles are available also for your solution.
